Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization Unit

Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization Unit

  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
  • Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit
Product Details:
Contact Now
Detailed Product Description
颜色: 自定义, 客户的要求 原产地: Sichuan, China
品牌: RT 用途: 净化
重量: 4500 KG 尺寸(长×宽×高): 变化
保修期: 1年 核心卖点: 环保
机械测试报告: 可提供 视频出厂验货: 可提供
核心组件: PLC, 压力容器 应用程序: 天然气脱硫
认证: ISO9000、ISO14000 OEM: Avaliable
配置: 固定 容量: 6X104 Nm3/d
类型: MEDA脱硫 条件: 新建
适用行业: 能源与矿业 保修后服务: 视频技术支持

Product features



Description:



Molecular sieve is an alkali metal aluminosilicate crystal with framework structure and uniform microporous structure. It is an adsorbent with excellent performance, high adsorption capacity and adsorption selectivity.



Firstly, there are many channels with uniform pore size and well arranged pores in the structure of molecular sieves, which not only provide a very large surface area, but also restrict the entry of molecules larger than the pores;



secondly, due to the characteristics of ionic lattice, the surface of molecular sieves has high adsorption capacity for unsaturated molecules, polar molecules and easily polarized molecules Polar molecule, the molecular diameter is smaller than the molecular sieve pore diameter. When the feed gas containing trace water passes through the molecular sieve bed at room temperature, the trace water and mercaptan are absorbed, thus reducing the water and mercaptan content in the feed gas, realizing the purpose of dehydration and desulfurization.



The adsorption process of molecular sieve includes capillary condensation and physical adsorption caused by van der Waals force. From the Kelvin equation, it can be seen that the capillary condensation weakens with the increase of temperature, while the physical adsorption is an exothermic process, and its adsorption weakens with the increase of temperature and increases with the increase of pressure;



therefore, the adsorption process of molecular sieve is usually carried out at low temperature and high pressure, while the desorption regeneration is carried out at high temperature and low pressure. Under the action of high temperature, clean and low pressure regeneration gas, the molecular sieve adsorbent releases the adsorbate in the micropore into the regeneration gas flow until the amount of adsorbate in the adsorbent reaches a very low level, and has the ability to absorb water and mercaptan from the feed gas, realizing the regeneration and recycling process of molecular sieve.



Technical parameters



Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 0





1 Medium Sour natural gas
2 Treatment capacity 6X104 Nm3/d
3 Inlet Temperature 45℃
4 Inlet Pressure 3.48-4.98 MPa
5 Materials 20G/GB5310



Company display



Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 2

        Perfect quality system and testing facilities                                                     Strong R & D and design capabilities

Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 4

        120 R&D team provide the system solutions.                                                                      Timely delivery capability



Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 6



Perfect quality system and testing facilities                                               Good after-sales service and operation technical support



Our projects



Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 8

Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 10





Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 12



Company profile



Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 14

Our cerficate



Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 16





Natural Gas Molecular Sieve Desulfurization Package Natural Gas Desulfurization  Unit 18
